Preamplifier / DI Box
- Class A
- Balanced microphone input stage without transformer
- 40 dB variable gain
- Output: +26 dBu @ 1 kHz
- Inherent noise: -90 dB @ 20 Hz to 20 kHz
- HiZ instrument input
- Switchable high pass filter: -6 dB per octave @ 80 Hz
- Additional Vari filter (variable high pass filter): 70 - 400 Hz in 21 steps
- 15 dB input pad
- LED level meter
- Phase reverse
- 48 V phantom power switchable
- Build: 9.5" / 1 U
