Audio-Technica VM510CB

The VM510CB conical stylus cartridge is the entry-level 500 Series model in Audio-Technica’s new VM cartridge line – a line that harks back to A-T’s early days as a manufacturer primarily of high-end phono cartridges, while also incorporating today’s advanced technology. Like all VM cartridges, the VM510CB is equipped with dual magnets that are positioned to match the left and right channels in the stereo record groove for outstanding channel separation and extended frequency response. The cartridge’s 0.6 mil conical bonded stylus tracks the center of the record groove for reliable performance and excellent fidelity. Includes mounting hardware. Features VM dual magnet cartridge with 0.6 mil conical stylus Aluminum cantilever Paratoroidal coils improve generating efficiency Center shield plate between the left and right channels reduces crosstalk Durable low-resonance polymer housing Specifications

Cartridge & Stylus
Frequency Response	20-20,000 Hz
Channel Separation	25 dB (1 kHz)
Vertical Tracking Angle	23°
Vertical Tracking Force	1.8-2.2 g (2.0 g standard)
Stylus Construction	Bonded round shank
Recommended Load Impedance	47,000 ohms
Coil Impedance	2,700 ohms (1 kHz)
DC Resistance	800 ohms
Coil Inductance	460 mH (1 kHz)
Output Voltage	5.0 mV (at 1 kHz, 5 cm/sec)
Output Channel Balance	1.5 dB (1 kHz)
Stylus Shape	0.6 mil conical
Cantilever	Aluminum pipe
Static Compliance	35 x 10-6 cm/dyne
Dynamic Compliance	8 x 10-6 cm/dyne (100 Hz)
Mounting	Half-inch
Dimensions	17.3 mm (0.7") H x 17.0 mm (0.7") W x 28.2 mm (1.1") D
Accessories Included	Four cartridge installation screws (5 mm x 2, 10 mm x 2), two washers, two hexagon nuts
Mounting Feature	Half-inch mount
Recommended Load Capacitance	100-200 pF
Replacement Stylus	VMN10CB
Stylus Size	0.6 mil
Type	VM Type
Weight	6.4 g (0.2 oz)
