Analog Mixing and Recording Console
Заводская спецификация и комплектация с сайта производителя
- 24 Fader console with 2 line level inputs per channel
- Switch from mix to record input at the push of a button
- 24 Direct outputs
- 4 Groups and mix bus with 2-band EQ and switchable inserts
- Marinair transformers on Mix, AFL, CUE buses
- 24 Switchable channel inserts
- 48-Channel mix mode
- 2 x 1073 preamps and two DI inputs
- 2 x Headphone amplifiers with independent source selection
- 2 x Stereo reverb returns
- Stereo width for the mix bus
- Backlit stereo VU meter with source selection
- 3 x Speaker outputs
- 3 x External inputs
- 3 Solo modes: SIP, AFL, PFL
- Dual cue system and three-way talkback system
- Recall function for saving / loading multiple sessions
- 2 x 500 slots with different routings (modules not included)
- Third input per channel enables inline use
- Dimensions (W x D x H): 1190 x 850 x 500 mm
- Weight: 53 kg
